16Pcs Lift Beehive Valve Spring .600″ Lift Rated For GM All LS LS1 LS2 LS3 LS7

Brand: speedracingturbo
SKU: SP-1590

Roll over image to zoom in

$30.00

Status:3 in stock

16Pcs Springs 600" Lift Rated For GM All LS LS1 LS2 LS3 LS7 Engines oem pac1218

LS VALVE SPRINGS Pac1218-16 For GM LS1 LS2 LS3 LS6 4.8 5.3 6.0 6.2L - .600" LIFT

OE/OEM Part Number:1218 PAC1218

The 16Pc-1218 Spring Kit is a drop-in high performance spring kit for all OE LS cylinder heads and is rated for up to .600" lift. This spring kit uses all OE hardware, including seats, retainers, and locks and is 100% drop-in.

The 16Pc-1218 are an ovate beehive spring that has increased loads, rates and frequencies for more aggressive cams.

This is a full set of 16 springs.

Specification:

Number of Springs Per Valve: Single

Outside Diameter of Outer Spring (in): 1.290 in.

Coil Bind Height (in): 1.140 in.

Damper Spring Included: No

Install Load: 130lbs

Install Height: 1.800"

Open Height: 1.175"

Open Load: 318 lbs

Spring Rate (lbs/in): 313 lbs./in.

Inside Diameter of Outer Spring (in): 0.885 in.

Valve Spring Style: Beehive

Package Includes:

16X Beehive Valve Spring

SKU: SP-1590 Category: Engine Head Gasket Kits

16Pcs Springs 600″ Lift Rated For GM All LS LS1 LS2 LS3 LS7 Engines oem pac1218

LS VALVE SPRINGS Pac1218-16 For GM LS1 LS2 LS3 LS6 4.8 5.3 6.0 6.2L – .600″ LIFT

OE/OEM Part Number:1218 PAC1218

The 16Pc-1218 Spring Kit is a drop-in high performance spring kit for all OE LS cylinder heads and is rated for up to .600″ lift. This spring kit uses all OE hardware, including seats, retainers, and locks and is 100% drop-in.

The 16Pc-1218 are an ovate beehive spring that has increased loads, rates and frequencies for more aggressive cams.

This is a full set of 16 springs.

Specification:

Number of Springs Per Valve: Single

Outside Diameter of Outer Spring (in): 1.290 in.

Coil Bind Height (in): 1.140 in.

Damper Spring Included: No

Install Load: 130lbs

Install Height: 1.800″

Open Height: 1.175″

Open Load: 318 lbs

Spring Rate (lbs/in): 313 lbs./in.

Inside Diameter of Outer Spring (in): 0.885 in.

Valve Spring Style: Beehive

Package Includes:

16X Beehive Valve Spring

Additional information

Weight	35 kg
Dimensions	45 × 25 × 14 cm
